Vacuum Seal Jar
Configuration shown · Empty clear 89-400 jar shown without a vacuum-forming cap or evacuation lid

Food & Sauce

Vacuum Seal Jar

A 16 US fl oz clear, straight-sided Type III glass jar with an 89-400 continuous-thread finish and 3-inch opening. Select the closure and qualify the complete pack for the intended use.

16 oz / 473 mL89-400 CT finish283 g reference glass
Stock status
In stock
Lead time
2–3 weeks

Final availability, dimensions, materials, assembled components and commercial terms are confirmed against the selected drawing and approved sample.

Broad access opening

The broad opening supports filling, scooping and finish inspection

Qualified hot-fill closure option

Match the 89-400 metal cap and plastisol liner to the validated process

Straight label panel

A 66 mm-high wrap zone keeps product and closure information easy to organize

Vacuum Seal Jar profile

A 16 oz straight-sided jar with distinct hot-fill and external-vacuum closure options.

Vacuum route, closure mechanics & inspection

Closure and process decisions for reduced-pressure packaging.

BGP-FS-2270 is a 16 oz jar with an 89-400 continuous-thread finish. Vacuum developed during a qualified hot-fill process and vacuum created by an external evacuation system require different closure arrangements. Select the complete jar, lid and process combination for the intended product.

01

Define the intended vacuum system

Vacuum created during a qualified hot-fill process differs from vacuum produced by an external evacuation system. Tell us which method you intend to use so the lid, gasket and inspection requirements can be specified for that route. The complete assembly requires qualification.

02

Use the complete 89-400 finish designation

The 89 mm designation identifies the nominal finish diameter, while 400 identifies the thread profile. Do not assume that an 89-405 cap, wide-mouth Mason lid or pump attachment is compatible. Match components using the production drawing and approved samples.

03

Set headspace through process qualification

The intended fill level must accommodate the product, closure and qualified process. Have the responsible product and process teams establish the requirements for the actual formulation and pack rather than using a generic headspace setting.

04

Match the liner to the process

For a hot-fill configuration, confirm the suitability of the metal cap and plastisol liner with the closure supplier. The agreed specification should address the glass sealing surface and the conditions of the validated process.

05

Assess seal performance over the intended life

An initial vacuum reading does not establish performance throughout distribution and storage. Agree suitable inspection points and integrity assessments for the actual product, closure and process, with traceability to the relevant component lots.

06

Keep preservation separate from vacuum claims

Vacuum is a package condition, not proof that a food is shelf-stable. The responsible food-safety and process specialists must establish product preservation and storage requirements for the complete formulation, container and closure.

Application guide

Choose the closure and vacuum system around the actual product.

The 16 oz format can be evaluated for qualified food-processing or externally evacuated dry-storage systems. Each requires its own closure specification and complete-pack assessment.

Red fruit spread being spooned into an open clear glass jar

Hot-filled foods

Jams, fruit spreads and acidic sauces

For products with a qualified hot-fill process and compatible metal plastisol closure. The responsible food-safety and process specialists establish the formulation, processing and storage requirements; the jar’s straight body provides a clear view of the contents.

  • Confirm liner and process compatibility
  • Assess the 89-400 sealing surface
  • Define the qualified inspection plan
Spoonful of relish held above a filled glass jar

Spoonable condiments

Relishes, chutneys and thick sauces

A 3-inch opening offers access for spoonable and particulate foods. Review the product, filling method, sealing surface and closure with the responsible process team, including the conditions that challenge the intended pack.

  • Declare maximum particle dimensions
  • Include sealing-surface inspection
  • Qualify the actual product and process
Open straight-sided glass jar containing coffee beans

Externally evacuated dry goods

Coffee, grains and dehydrated ingredients

For dry-storage concepts using a purpose-designed 89-400 lid, gasket and evacuation interface. Qualify the jar, lid and tool together, including vacuum retention and repeated access. External evacuation is not a substitute for a validated preservation process for moist foods.

  • Qualify the complete lid and tool
  • Measure vacuum retention over access cycles
  • Keep dry-product moisture within specification

Closure choice changes seal behavior: specify the actual metal or plastic cap and liner rather than treating every 89-400 lid as equivalent.

FAQ

Technical questions about the 16 oz 89-400 vacuum-seal format.

Answers on the jar specification, closure matching, vacuum systems and preservation requirements.

How can a hot-filled jar develop vacuum?

Pressure can fall as a sealed hot-filled pack cools. Whether this is suitable depends on the qualified product, process and closure system; it is not a standalone preservation method.

Are 89-400, 89-405 and wide-mouth Mason lids interchangeable?

Do not assume interchangeability. Match the full finish designation, sealing components and production drawing, then confirm fit with approved samples.

Does vacuum make moist food safe at room temperature?

No. Safe storage must be established for the actual formulation, container, closure and preservation process by the responsible specialists.

When should vacuum be checked?

Use inspection points established in the qualified process and shelf-life plan. Assessment should cover the relevant distribution and storage conditions, rather than relying on a single initial reading.

Next step

Send us the Vacuum Seal Jar brief.

Share your product, fill volume, preferred closure and destination market. We will review the matching drawings, available configurations and sample options before preparing a quote.

  • 01Send the briefProduct, volume, closure and market
  • 02Get the optionsMatching drawings and configurations
  • 03Approve the sampleConfirm the pack before production
